2023 Magni Hth 20.10
Quick Enquiry
Key Features and Details
- Year2023
- GVM—
- Body TypeForklifts & Telehandlers
- Stock No.OAG-AD-24855032
- Length—
- Tare—
- ATM—
- Sleepss—
- Reg #—
Dealer Comments
The HTH 20.10 telescopic handler is ideal for moving large, bulky loads in complete safety.
Able to lift up to 20 tonnes, it is compatible with a wide range of accessories, making it extremely versatile. Equipped with an RFID system which provides automatic recognition of the various attachments used, this telescopic handler is able to meet a wide range of applications in heavy industry. Its four-wheel drive system, three manoeuvring modes and high ground clearance makes it highly manoeuvrable on all terrains.
Specifications:
o Lifting capacity: 19,999 kg
o Capacity at maximum height: 15,000 kg
o Lifting height: 9.70 m
o Reach: 5.10 m
o Engine: Volvo TAD552 VE - Stage IIIA
o Rated power: 160 kW (218 hp) 2.300 rpm
o Number of gears: 2/2
o Hydraulic system: 350 bar (Load Sensing)
o Length: 6.13 m
o Width: 2.55 m
o Ground clearance: 400 mm
o Unladen weight: 24,000 kg
o Travel speed: 25 km/h
o Climate control as standard: Yes
o Automatic accessory recognition: Yes
o Reversable fan drive: Yes
o Year: 2023
o Hours: 160
o 20T Container Fork Positioning Carriage
o Hook
o Mine Spec
The HTH 20.10 telescopic handler is ideal for moving large, bulky loads in complete safety.
Able to lift up to 20 tonnes, it is compatible with a wide range of accessories, making it extremely versatile. Equipped with an RFID system which provides automatic recognition of the various attachments used, this telescopic handler is able to meet a wide range of applications in heavy industry. Its four-wheel drive system, three manoeuvring modes and high ground clearance makes it highly manoeuvrable on all terrains.
Specifications:
o Lifting capacity: 19,999 kg
o Capacity at maximum height: 15,000 kg
o Lifting height: 9.70 m
o Reach: 5.10 m
o Engine: Volvo TAD552 VE - Stage IIIA
o Rated power: 160 kW (218 hp) 2.300 rpm
o Number of gears: 2/2
o Hydraulic system: 350 bar (Load Sensing)
o Length: 6.13 m
o Width: 2.55 m
o Ground clearance: 400 mm
o Unladen weight: 24,000 kg
o Travel speed: 25 km/h
o Climate control as standard: Yes
o Automatic accessory recognition: Yes
o Reversable fan drive: Yes
o Year: 2023
o Hours: 160
o 20T Container Fork Positioning Carriage
o Hook
o Mine Spec
3. Price on Application - Price will be disclosed to you upon contacting us.
